20KWH 51.2V Lifepo4 Battery ,Hybrid Grid Energy Storage ,large storage battery

51.2V 20KWH LFP Battery

51.2V 20KWH CAN Communication Port Hybrid Grid Energy Storage Lithium Iron Lifepo4 Battery Hybrid Solar Inverter

Key Feature

Application：Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts

Max Load Quantity(cells)：16

Cycle Life：6000 cycles

Model Number：51.2V

Operating Temperature(℃)：-20-60

Cathode Materials：LiFePO4

Brand Name：Max Poweress

Dimension (L*W*H)：592*400*176mm

Weight：43.6kg

Place of Origin：Guangdong, China

Voltage：51.2V

Warranty：10 Years

OEM/ODM：Accepatable

Application：Home Energy Storage Systems

Battery Type：LFP(LiFePO4)

Module Configuration：16S1P

Discharge cut-off voltage(v)：47V

Over current charging protection(A)：110A

Over current protection(A)：120A

Get A Quote Customize Battery

Features and advantage

1. Safety: telecom base station lifepo4 battery, built-in BMS、Inverter, no fire, none explosive.
2. Clean and green energy, does not contain toxic material.
3. designed for household electricity use, with easy assembly to meet typical household power needs.
4. Prolonged life cycle, after 2000 cycles, the residual capacity exceeds 80% of its original capacity.
5. No memory effect, highly efficient charging at any time.
6. Wide operating temperature: -10 ~ 55 ° C.
7. The integrated 51.2V low-voltage stacked system employs imported chips, multiple protections, and ultra-high precision real-time monitoring.
8. SOC accuracy is optimized, with SOC error within 3%, based on extensive testing data.
9. Communication protocols include RS485/CAN/RS232/UART and Bluetooth.
10. With individual package, clear warning mark, logo. Instruction manual printed in colors.

Specification

Application：Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts
