12.8V200AH

12.8V LiFePO4 battery pack for lead acid replacement 12.8V200Ah 12V LFP battery pack

Key Feature

Voltage ： 12.8V

Capacity ： 200Ah

Battery type : Lifepo4 Battery

Cycle life： 2000-6000 times

Warranty ：2 Year

OEM ：Available
Application ：electric motorcycle, forklift, golf cart ,boat

Cell Brand ：CATL,BYD,EVE,CALB,SVOLT,LG,REPT,Gotion,ANC etc.

Certification：ISO9001，CE， ROSH，UN38.3，CNAS，MSDS,KC

Features and advantage

1. Safety: telecom base station lifepo4 battery, built-in BMS, no fire, none explosive
2. Clean and green energy, does not contain toxic material
3. Powerful
4. Prolonged life cycle, after 2000 cycles, the residual capacity exceeds 80% of its original capacity.
5. No memory effect, highly efficient charging at any time
6. Wide operating temperature: -10 ~ 55 ° C
7. Small size and light weight.
8. Low self-discharge rate: <3% monthly
9. With individual package, clear warning mark, logo. Instruction manual printed in colors
10. Max Power LiFePO4 Battery have high energy Density, Long cycle life,widely work temperature range and good safety performance, Mainly use in solar power system.wind power,and others energy storage power systems. UPS system, telecommunications system.As well as electric tools ,electric bicycles ，electric motorcycles,military equipment amd other fields.

Specification

Item	General Parameter		Remark
Standard capacity（0.2C5A）	200Ah
Rated voltage	12.8V		(Work voltage：3.20V)
Max.Charge voltage	14.6V		(Single Ave. charge Voltage)
Cut-off voltage	10V		(Single Ave. Discharge Voltage)
Standard charge current	100A		0.5C
charging Time	About 2h
Max Continuous discharge current	100A		0.5C
Peak discharge current	150A>10S
Battery dimension	532207215mm
Total weight（Approx.)	19kg
Impedance（Max, at 1000Hz.）	≤ 40mΩ
Charge method (CC/CV)	Standard	0℃～45℃
	discharge	-20℃～65℃
	storage	0℃～45℃
The data is for reference only, all parameters can be customized
